HEAD AND NECK DEVELOPMENT, PHARYNGEAL ARCH, GROOVE, AND POUCH DEVELOPMENT

In the human embryo, the stomodeum or primitive mouth cavity, a shallow depression lined with ectoderm, is separated from the cephalic end of the pharyngeal gut by the buccopharyngeal membrane, which ruptures during the fourth week of gestation.
Frontal view of an embryo at 4 to 5 weeks of age. Observe the branchial arch formation and the ruptured buccopharyngeal membrane.

Just anterior to the buccopharyngeal membrane, a midline diverticulum known as the Rathke pouch develops in the oral ectoderm of the roof of the primitive oral cavity. This evaginating pouch comes in contact with a pouch developing from the floor of the diencephalon. Further development of these two opposed structures gives rise to the pituitary gland.
During the fourth and fifth weeks of gestation, as the buccopharyngeal membrane is degenerating, communication is established between the future oral cavity and the pharynx. Concomitant with this event, out-pouchings of the pharyngeal gut develop just posterior to the ruptured buccopharyngeal membrane, forming five pairs of pharyngeal pouches that invade the mesenchyme laterally. Although it was once thought that the neural crest cells of the pharyngeal arches were responsible for patterning skeletal components of the arches, it is now clear that the endodermal lining of the pharyngeal pouches regulates this patterning.
Concurrent with the formation of the pouches in the pharyngeal wall, four pairs of grooves develop around the stomodeal neck area on the lateral surface of the embryo. These pharyngeal grooves (branchial grooves) invade the underlying mesenchyme approximating, but not contacting, their corresponding pharyngeal pouches. Invasion by the pouches and the grooves produces a condensation of mesenchymal tissue interposed between successive pairs of pouches and grooves (clefts). These five bars of condensed mesenchymal tissue are the pharyngeal (branchial) arches (see Figs. 5-2, 5-3A, 5-3B, 5-3C, and 5-4).

Developing face. (A) Fourth week. (B) Fourth to fifth week. (C) Fifth to sixth week. (D) Sixth to seventh week. Note how the nose develops and the eyes appear more anteriorly placed, illustrating the nasolacrimal groove.


Scanning electron micrograph of a stage 15 (8.0-mm) human embryo in frontal view. Observe the maxillary processes, mandibular process, hyoid and third pharyngeal arch processes, and nasal pits. ×52.

 Scanning electron micrograph of a stage 17 (11.7-mm) human embryo in lateral view. Observe the nasal pits, median and lateral nasal processes, maxillary processes, mandibular process, and hyoid arch. ×57.

Scanning electron micrograph of the face of a stage 18 (17.5-mm) human embryo in frontal view. Observe the fused processes making up the nose, the maxillary processes, and the mandibular processes delineating the mouth. ×14.

Early development of the pharyngeal grooves and pouches. (A) Early development. (B) Later development. Observe the second arch overgrowing the second, third, and fourth grooves leaving a cervical cyst in drawing B. Note the diverticula of pouches three and four as each develops dorsal and ventral prolongations.

The mesenchymal cells forming much of the ventral regions of the developing pharyngeal arches are derived from neural crest cells originating from the vicinity of the midbrain region and the rhombomeres. During early pharyngeal arch formation, these cells express homeobox gene (Hox gene) products indicative of the region of their origin.
Continued development and growth of the arches results in their fusion in the anterior midline. Each arch will develop its own bone, cartilage, vascular, muscular, and nerve components. The arches form sequentially from rostral to caudal, with the first arch being most highly developed and the last arch being poorly developed. The first and second arches are named “mandibular” and “hyoid” arches, respectively, whereas the remaining three are unnamed. The discussion of pharyngeal arch derivatives that follows is summarized in Table.

Pharyngeal Arch Derivatives and Their Innervation
Arch
Skeletal
Ligaments
Muscle
Nerve
I
Mandibular
Meckel's cartilage
Maxillae
Mandible
Malleus
Incus
Sphenomandibular
Anterior ligament of malleus
Muscles of mastication (temporalis, masseter, medial and lateral pterygoids)
Tensor veli palatini
Tensor tympani
Digastric (anterior belly)
Mylohyoid
Cranial nerve V (trigeminal) mandibular div.
II
Hyoid
Reichert's cartilage
Hyoid (part)
Lesser cornu
Body, upper part
Styloid process
Stylohyoid
Muscles of facial expression (platysma, buccinator, frontalis, occipitalis, auricular, orbicularis, oculi, oris)
Stapedius
Digastric (posterior belly)
Stylohyoid
Cranial nerve VII (facial)
III
Hyoid (part)
Greater cornu
Body, lower part
Stylopharyngeus
Cricothyroid
Pharyngeal constrictorsa
Cranial nerve IX (glossopharyngeal)
Cranial nerve X (vagus)
External branch of
superior laryngeal nerveb
IV
Thyroid cartilage
Pharyngeal plexusc
VI
Laryngeal cartilages (cricoid, arytenoid, corniculate, cuneiform)
Intrinsic laryngeal muscles-except cricothyroid
Cranial nerve X (vagus) Recurrent laryngeal nerveb

a The origin of some of the muscles of the pharynx is as yet unclear. The pharyngeal constrictors may in fact receive innervation from more than one source.
b Although this named branch of the vagus nerve is traditionally described as the motor innervation to the identified laryngeal muscles, it is important to remember that the motor fibers of the vagus nerve, at least in this region, are actually motor fibers contributed to the vagus nerve from the cranial portion of the accessory nerve (cranial nerve XI).

c Several of the pharyngeal and associated muscles of the soft palate are innervated by branches of the pharyngeal plexus—a complex of the nerves located on the posterior aspects of the pharynx consisting of contributions from cranial nerves IX and X (IX is sensory, whereas X is motor, although these motor fibers are contributed from XI). Fibers from the superior cervical gaglion also contribute to the pharyngeal plexus, serving vasomotor functions.
